GPS Shield With Antenna

GPS Shield With Antenna

Shield Arduino con receptor GPS y antena cerámica. Basado en el módulo Ublox NEO-6M de alta sensibilidad. Incluye slot para memoria microSD.

COD: EMCS01107S

Peso: 0.021 Kg

Disponibilidad: Sin Stock

Su correo electrónico:

ARS 1021.00

Cantidad:

El producto no está disponible para la venta en este momento

Características

The GPS Shield is base on the ublox's NEO-6M receiver module, and the footprints is compatible with Arduino/MEGA boards. The regular GPS pins (RX, TX) can be connected to D0-D7 of Arduino. Support software SerialPort and Micro SD card interface.

It's very easy to use. You just need read SerialPort and then will get the GPS data. The GPS Shield module interfaces to the customer application via one serial port, which uses CMOS voltage levels. support 3.3V / 5V IO operating. That's means 100% all Arduino mainboard compatible.

Features

  • Arduino, Mega and Crowduino compatible
  • With Micro SD interface
  • 3.3v and 5v logical voltage compatible
  • Active antenna design with high receive sensitivity, compatible normal antenna
  • Extremely fast time to first fix at low signal level

Package list

  • GPS Shield PCBA X 1
  • IPC Antenna X 1
