Relay Socket For ESP-01S

ESP8266 ESP-01S Relay

Módulo relé con zócalo para montar un módulo WiFi ESP-01S (no incluido). Ideal para ser aplicado en proyectos de domótica, casas inteligentes, internet de las cosas (IoT) y proyectos DIY.

COD: HTHS0205

Peso: 0.050 Kg

Disponibilidad: En Stock

Su correo electrónico:

ARS 527.00

Cantidad:

El producto no está disponible para la venta en este momento

Características

Description:

 This WIFI relay based on AI-Thinker ESP-01S WIFI module. It is designed for smart home, Internet of thing and other DIY project.
With this smart relay, you will easy to DIY your smart switch to control any device by your phone anywhere.




Product parameters:

  • Product size: 37 * 25mm.
  • Operating voltage: DC5V.
  • Communication: WIFI (ESP8266 module).
  • Transmission distance: the maximum transmission distance of 400m (open environment, mobile phone equipped with WIFI module).
  • Load: 10A/250VAC 10A/30VDC, the relay pull 100,000 times.



Links!!:

  • Download:https://pan.baidu.com/s/1cHBbbw
  • https://www.openhacks.com/page/productos/id/2313/title/ESP-01S-ESP8266-Wifi-Module#.WnIOkWmuxhE




Usage:

1. Power it by DC 5v.
2. Open your phone WLAN then connect the WiFi ESP8266-XXXX, Power word:12345678.
3. Open the ESP8266 Controller.app ( Installed it in your android phone before).
4. Set IP Address: 192.168.1.1 than you can control your device via the wifi relay module.





Package included:

1 x ESP8266 ESP-01S Relay Module( Not Include ESP-01S WIFI Module).
