WiPy 2.0

WiPy 2.0

Módulo Wipy V2.0 con doble procesador que integra Bluetooth y WiFi (ESP32) compatible con plataforma MicroPython. A diferencia de su antecesor, agrega más entradas analógicas y mas RAM (512 Kb), entre otras funcionalidades adicionales.

COD: PY00005

Peso: 0.029 Kg

Disponibilidad: En Stock

Su correo electrónico:

ARS 1112.00

Cantidad:

El producto no está disponible para la venta en este momento

Características

Features:

  • Powerful CPU, BLE and state of the art WiFi radio.
  • 1KM Wi Range.
  • MicroPython enabled, the Linux of IoT for fast deployment.
  • Fits in a standard breadboard (with headers).
  • Ultra-low power usage: a fraction compared to other connected micro controllers.
  • Hardware floating point acceleration.
  • Python multi-threading.





Processing:

  • Espressif ESP32 chipset.
  • Dual processor + WiFi radio System on Chip.
  • Network processor handles the WiFi connectivity and the IPv6 stack.
  • Main processor is entirely free to run the user application.
  • An extra ULP-coprocessor that can monitor GPIOs, the ADC channels and control most of the internal peripherals during deep-sleep mode while only consuming 25uA.



Interfaces:

  • 2 x UART, 2 x sPI, I2C, I2S, micro SD card.
  • Analog channels: 8×12 bit ADCs.
  • Timers: 4×16 bit with PWM and input capture.
  • DMA on all peripherals.
  • GPIO: Up to 24.



Hash/Encryption:

SHA, MD5, DES, AES.



WiFi:

802.11b/g/n 16mbps.



Bluetooth:

Low energy and classic.



RTC:

Running at 32KHz.



Power:

  • 3.3V to 5.5V.
  • 3V3 output capable of sourcing up to 550mA.



Security & Certifications:

  • SSL/TLS support.
  • WPA Enterprise security.
  • FCC – 2AJMTWIPY2R.
  • CE 0700.



Memory:

  • RAM: 512KB.
  • External flash: 4MB.
  • Hardware floating point acceleration.
  • Python multi-threading.



Size:

42mm x 20mm x 2.5mm (excluding headers).



Weight:

  • 5g
  • 29g (Packaged)
