8x8 Full-color RGB LED Matrix Driver Module
Módulo basado en el ATMega 328. Se trata en rasgos generales de un Arduino UNO (no posee pines de E/S) pero especializado y optimizado para control y manejo de matrices de puntos RGB de 8x8. El producto no incluye la matriz de 8x8 para visualizar los puntos. La misma se vende por separado. Funciona con interfaz UART (es necesario conversor TTL), SPI e I2C.
COD: IDST1149
Peso: 0.022 Kg
Disponibilidad: En Stock
ARS 27752.00
El producto no está disponible para la venta en este momento
Características
Description:
A full color RGB display driver designed to drive a tri-color 8*8 dot matrix.
Features:
Full-color RGB Dot matrix driver board is a Arduino Dashboard module which specialized designed for RGB full-color dot matrix, This module not only can drive the RGB Dot matrix independently but also can be used as Arduino Control panel. It is very convenient and practical, on-board chip is ATmega 328Chips, the board also raise above SPI Interface, you can programmer bootloader to 328 Chip free. Drawback unlike other Arduino Uno, there is no corresponding leads I / 0 Out of the mouth, but leads to a number of I2C Interface and power supply interface; 6Bit color supported; Support hardware 16MHz PWM; Without any additional circuitry; Dedicated GPIO and ADC interface; Support hardware UART and IIC communication; 24 Channel constant current channel current up to each channel 1100mA; 8 channel constant current source drive current up to each channel 500mA; Operating current: 300mA; Operating temperature range: -10ºC~+50ºC
Specifications:
- Type : Module.
- SPI Interface.
- Dedicated GPIO and ADC interface.
- Power supply: +5 V to +5.3 V.
- Operating voltage: 5V DC.
- Support hardware UART and I2C communication.
- 8 channel constant current source drive current up to each channel 500mA.
- 24 Channel constant current channel current up to each channel 1100mA.
- erating current: 300mA.
- MCU: ATMega328.
- Use For : For Arduino.
- Module Function : Board.
- Dimension(cm) : 6.6 x 6.0 x 1.2.
- Net Weight(kg) : 0.022.
- Operating temperature range: -10ºC~+50ºC.
