MyoWare Power Shield
Diseñado para insertar dos pilas CR2032 y brindar alimentación a el sensor muscular MyoWare.
COD: SFDEV13684
Peso: 0.009 Kg
Disponibilidad: En Stock
ARS 6966.00
El producto no está disponible para la venta en este momento
Características
Description: The MyoWare Power Shield is designed to take two standard CR2032 coin cell batteries to power the MyoWare Muscle Sensor. We have made this board in a way that the coin cell batteries are connected in parallel for extended capacity at a nominal 3.0V. Connecting the MyoWare Muscle Sensor to battery power allows for a cleaner signal while also eliminating the possibility of creating a dangerous current path to the power grid.
One thing to note is that due to the size of the batteries, the remote cable header on the MyoWare Miscle Sensor can’t be passed through. If you need access to these connections, this Power Shield will need to be stacked above the board(s) that need access.
The MyoWare Muscle Sensor, that this shield attaches to, is an Arduino-powered, all-in-one electromyography (EMG) sensor from Advancer Technologies. The MyoWare board acts by measuring the filtered and rectified electrical activity of a muscle; outputting 0-Vs Volts depending the amount of activity in the selected muscle, where Vs signifies the voltage of the power source.
Documents:
myoware_power_shield.pdf (58 Kb)
myoware_power_shield.zip (180 Kb)
